LeCroy WavePro 7100A

182 WM-OM-E Rev I
Figure 2
Determining Differential Time Measurements
The DDA-5005A enables accurate differential time measurements between two traces: for
example, propagation, setup and hold delays (see Figure 3).
Parameters such as Delta c2d+/- require the transition polarity of the clock and data signals to be
specified.
