178 WM-OM-E Rev I

To Turn Off Help Markers

1. Touch the Clear All button

to turn off Help Markers for all parameters.

2. To turn off Help Markers for individual parameters, touch the Px tab for the parameter in

question. Then uncheck the Always On checkbox. When you close this dialog, the Help

Markers for this parameter will no longer be displayed.
