X-Stream Operator’s Manual

WM-OM-E Rev I 167

Using X-Stream Browser to Obtain Status Information

Example:

Here is a case of an overflow condition, in which the amplitude of the waveform cannot be

determined:

1. Minimize the scope display by selecting File Minimize.

2. Touch the X-Stream Browser desktop icon to open the browser:

3. Touch the left scope icon ("Connect to a local X-Stream DSO device") in the X-Stream

Browser toolbar:

4. Select Measure Parameter in error (P1) Out Result:

Default Chapter3
