Specifications
Note: Specifications are subject to change without notice.
Vertical System
Bandwidth (-3 dB @ 50 ohms):*
WaveMaster 8600A & 8620A
†
6 GHz @ 50 ohms (at sample speed 20 GS/s)
WaveMaster 8500A
‡
DDA-5005A
5 GHz
WaveMaster 8400A, 8420
4 GHz
DDA-3000A 3 GHz
WavePro 7100A
5 mV/div to 1 V/div 1 GHz
2 mV/div to 4.99 mV/div 500 MHz
WavePro 7200A
10 mV/div to 1 V/div 2 GHz
5 mV/div to 9.95 mV/div 1 GHz
2 mV/div to 4.99 mV/div 500 MHz
WavePro 7300A
10 mV/div to 1 V/div 3 GHz
5 mV to 9.95 V/div 1 GHz
2 mV/div to 4.99 mV/div 500 MHz
* At max. channel sampling rate
†
Derates 50 MHz/ºC @ T>30 ºC
‡
Derates 20 MHz/ºC @ T>30 ºC
Input Channels: 4
Rise Time (typical):
WaveMaster 8600A & 8620A 75 ps (at sample speed >/= 20 GS/s)
WaveMaster 8500A
DDA-5005A
90 ps
WaveMaster 8400A, 8420 115 ps
DDA-3000A 150 ps
WavePro 7100A 400 ps
WavePro 7200A 225 ps
WavePro 7300A 150 ps
