X-Stream Operator’s Manual

WM-OM-E Rev I 157

totp Total Population

Definition:

Calculates the total population of a histogram between the parameter cursors.

Description:

The count for all populated bins between the parameter cursors is summed.

Example:

The total population of this histogram is 9.
