192 WM-OM-E Rev I
formerly on the right,
now on left.
Standard parameter.
Frequency Frequency: Period of cyclic signal
measured as time between every
other pair of 50% crossings.
Starting with first transition after left
cursor, the period is measured for
each transition pair. Values then
averaged and reciprocal used to
give frequency.
1/period Standard parameter.
Freq@level Frequency at a specific level and
slope for every cycle in waveform.
Reference levels and
edge-transition polarity
can be selected.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with JTA2 and
XMAP options.
Standard in SDA100G
and WavePro 7000A
scopes.
FWHM Measures the width of the largest
area histogram peak at half of the
population of the highest peak.
Available with DDM2,
JTA2, XMATH, XWAV,
CAN02, SDA, and
XMAP options.
Standard in
DDA-5005A, SDA100G,
and WaveExpert
scopes.
FWxx Measures the width of the largest
area histogram peak at xx% of the
population of the highest peak.
Available with DDM2,
JTA2, XMATH, XWAV,
CAN02, SDA, and
XMAP options.
Standard in
DDA-5005A, SDA100G,
WaveExpert, and
sampling scopes.
Half period Half period of a waveform. Reference levels and
edge-transition polarity
can be selected.
Hysteresis argument
used to discriminate
levels from noise in
