X-Stream Operator’s Manual
WM-OM-E Rev I 407
Description All local features between the parameter cursors for an input waveform
are identified. The local baseline-to-trough amplitude is determined for
each feature, and the average is returned as taa. Provided for histograms
is the local baseline-to-trough amplitude for each local feature between
the parameter cursors.
Parameter Settings Selecting this parameter displays a hysteresis-dialog for setting the
hysteresis value to a specified number of vertical divisions.
taa+ Track Average Amplitude+
Definition The average local baseline-to-peak amplitude for all local features.
Description All local features between the parameter cursors for an input waveform
are identified. The local baseline-to-peak amplitude is determined for
each feature, and the average is returned as taa+. Provided for
histograms is the local baseline-to-peak amplitude for each local feature
between the parameter cursors.
Parameter Settings Selecting this parameter displays a hysteresis-dialog for setting the
hysteresis value to a specified number of vertical divisions.
