Pattern Length (Seconds)
Cycles in One Pattern
Length
ACSN
5.00E-8 4 27.54 dB
6.25E-8 5 26.97 dB
7.50E-8 6 26.78 dB
8.75E-8 7 26.57 dB
1.000E-7 8 26.47 dB
1.125E-7 9 26.41 dB
1.250E-7 10 26.30 dB
As ACSN readings get higher, small amounts of noise cause greater changes in
dB. This is because high readings mean correlation was very close to 1.
Examples:
Correlation ACSN
.9995 33.0 dB
.9990 30.0 dB
.9985 28.2 dB
.9980 27.0 dB
.9975 26.0 dB
.9970 25.2 dB
