Connect the EV3 Brick to your computer by USB cable or wirelessly
using either Bluetooth or Wi-Fi.
USB Cable
Using the USB cable, plug the Mini-USB end into the EV3 Brick’s PC
port (located next to Port D). Plug the USB end into your computer.
USB Cable connection
Connecting the EV3 Brick to Your Computer
EV3 TECHNOLOGY

LEGO EV3 Specifications

General

Processor	ARM9
RAM	64 MB
Storage	16 MB Flash
Display	178 x 128 pixel monochrome LCD
Power Source	6 AA batteries or rechargeable battery pack
Operating System	Linux-based
USB Ports	1 USB 2.0 host port
Connectivity	Bluetooth 2.1, Wi-Fi (via USB dongle)
Input Ports	4
Output Ports	4
Programming Languages	Python
Sensors	Touch, Color, Gyro
Speaker	Built-in
