BRICK INFORMATION
The Brick Information tab displays important information about
theEV3 Brick that is currently connected, such as EV3 Brick name,
battery level, firmware version, connection type, and memory bar. It also
gives you access to the Memory Browser and Wireless Setup tools.
PORT VIEW
The Port View tab displays information about the sensors and motors
connected to the EV3 Brick. When your EV3 Brick is connected to
the computer, this information is automatically identified and you
will be able to see the live values. If your EV3 Brick is not connected,
you can still set up the Port View tab manually. Select a port, then
select the appropriate sensor or motor from the list.
AVAILABLE BRICKS
The Available Bricks tab shows the EV3 Bricks that are currently
available for connection. You are able to choose which EV3 Brick
you want to connect to and the type of communication. Also, you
can disconnect an existing EV3 Brick connection.
You can find more information about how to use the Hardware Page
in the EV3 Software Help.
Hardware Page
Brick Information tab
Port View tab
Available Bricks tab
EV3 SOFTWARE
