LEGRAND CS102 User Manual

CS102 SNMP Card
User Manual
18
Output
Item
Description
Output Status
The status of the output source: "Other", "None", "Normal",
"Bypass", "Battery", "Booster" and "Reducer".
Output Number Lines
The number of UPS output lines
Output Voltage
The current output voltage, in Volts
Output Frequency
The current output frequency, in Hertz
Output Current
The current output current, in Ampere
Output Active Power
The current output power, in Watt
Output Apparent Power
The current output power, in VA
Output load
The current output load, in percentage
Bypass
Item
Description
Bypass Number Lines
The number of UPS bypass lines
Bypass Voltage
The current bypass voltage, in Volts
Bypass Frequency
The current bypass frequency, in Hertz
Bypass Current
The current bypass current, in Ampere
Bypass Power
The current bypass power, in Watt
Battery
Item
Description
Battery Status
The status of the UPS batteries: "Unknown", "Battery OK", "Low
battery", "Battery depleted", "Battery discharging" and "Battery
failure"
Temperature
The current internal UPS temperature, in Celsius degrees
Battery Voltage
The current total voltage of the battery, in Volts
Battery Capacity
Remaining
The estimated remaining battery capacity, in percentage
Time since in Battery
Power
The elapsed time (in seconds) since the UPS switched to battery
power. The value resets each time the UPS returns to normal mode
Battery Runtime
Remaining
The estimated remaining backup time, in minute
Alert
This section shows the active alarms of the UPS.
