CS102 SNMP Card
User Manual
28
Graphical view
Item
Description
Show
Specifies a data viewing period. It is used as an alternative to the
"From" and "To" fields.
From / To
You can display graphs by specifying a period. Click over the “From”
and “To” fields, and when the calendar appears, click the target date.
You can also enter the date (dd/mm/yyyy) in text. The correctness of
the date/time depends on the clock inside the CS102.
“Search” button
After you are done specifying the period in the “From” and “To”
fields, click the "Search" button on the right
“List” button
This button is used to display data logs in list form.
