Technical Data
51Leica HM500/Ref. 10 715 697/Version B
Ambient conditions
U
se +10 °C to +40 °C
+50 °F to +104 °F
30 % to 70 % relative humidity
70–1060 hPa air pressure
For optimum operation we recommend an ambient
temperature no higher than 25 °C!
Storage/transportation –25 °C to +70 °C
–13 °F to +158 °F
Up to 85 % relative humidity
Storage/transportation
Light source 0 °C to +40 °C
32 °F to +104 °F
30–70 % relative humidity
Standards
Medical electrical devices - Part 1:
General Requirements for Safety UL60601-1: 2003-04-25 Ed.1
Rev2006/04/26, CAN/CSA - 22.2 No. 601.1 - M 90: Issue
19990/01/01 Rev1998/02 Supl. 1 1994, Amend. 2 Febr. 1998 Upd
No2 and IEC/EN 60601-1-1: Issue 2000/12/01 Ed2
Electromagnetic compatibility IEC/EN 60601-1-2: Issue 2001
Guideline 93/42/EEC for medical products
According to SQS certificate Leica Microsystems (Schweiz) AG,
Surgical Division, has a management system which conforms
to the requirements of international standards
ISO 9001:2000/ISO 13485:2003 and ISO 14001:1996 for quality
management and environment management.
IEC/EN 60825-1: +A11+A2 Safety of laser products
Limitations on use
The Leica HM500 headmounted microscope may only be used
in closed rooms with a hard level floor.
Leica HM500 (System) classification: Class I, IP20
Leica HM500 trolley (optional)
H
eight without holder Approx. 1400 mm
Total width x depth Approx. 540 x 580 mm
Shelf area Approx. 400 x 360 mm
Total load capacity Max. 50 kg
Shelf load capacity 10 kg
Drawer load capacity 3 kg
Isolating transformer (optional)
Primary connection 115 V 60 Hz 230 V, 50/0 Hz
Power consumption 710 VA
Secondary 230 V or 115 V
Power rating 660 VA
Further technical data may be found in the
manufacturer’s user manual.
