Technical Data
50
Leica HM500/Ref. 10 715 697/Version B
Electrical data
P
ower pack
Power connection 110 VAC, 60 Hz
220 VAC, 50 Hz
Output 300 VA
Electrical protection class
(when charging) or
in battery operation II
Use only the power pack included in the scope of deliv-
ery of the system!
Leica HM500 footswitch and Leica HM500 Dental databox
Voltage 9.6 VDC/
SVHS socket max. 0.7 VAC/
RS232 socket max. 10 VDC
Power consumption max. 1.6 A while charging
Leica MLS500 light source
Power connection 100–240 VAC, 50–60 Hz
Power consumption max. 250 VA
Lamp 200 W metal halide
Leica HM500 headmounted microscope
This instrument contains an IR LED
that complies with the require-
ments for Class 1 lasers according
to EN 60 825-1:1994+A1: 2002 + A2:
2001.
Working distance approx. 300 to 700 mm
(measured from the eye)
Working distance approx. 200 to 600 mm
(measured from the microscope)
Focusing Autofocus, speed focus or manual
focus
Eyepieces Eyeglass-wearer interchangeable
eyepiece 14x, 20x (standard) and
26x, diopter adjustable
+/- 7 diopters
Total magnification Infinitely adjustable
2.9x – 7x with 20x eyepiece
(standard)
2.0x – 4.8x with 14x eyepiece
3.75x – 9x with 26x eyepiece
Field of view diameter 30–224 mm with 20x eyepiece
(standard)
30-224 mm with 14x eyepiece
25-176 mm with 26x eyepiece
LASER
CLASS 1
Eye distance Individually adjustable from
56–74 mm
Parallax compensation Automatic adjustment to the
selected focus
Headset Ergonomic headset with infinitely
variable height adjustment and
a
djustment of main movement axes.
Dimensions with standard eyepiece
Length 85 mm
Width 110–112 mm (depending on
interpupillary distance)
Height 68–79 mm (depending on inter-
pupillary
distance)
Swiveling angle 72°
Weight of HM500 microscope
approx. 300 g
Weight of headset approx. 290 g
Integrated camera
Camera type Autofocus color camera
Chip size
1
/2" CCD
Resolution Effective pixels
PAL 752 (H) x 582 (V)
NTSC 768 (H) x 494 (V)
Output S video
Leica HM500 footswitch
Battery NiMH battery with charge limiting,
warning function when charge
level < 10 %
Protection classes According to EN 60529, IPX1 and
IPX8 protection class for electrical
switching elements (when instru-
ment is plugged in)
Leica MLS500 light source
Lamp 200 W metal halide
Average service life 1200 h
Color temperature 5500–6000 K
Diameter of fiber-optic light Max 1.5 mm
guide
Dimensions (HxWxD) 169 x 297 x 355 mm
Weight Approx. 5.6 kg
Protection class (safety class)
I
Classification
according to EN55011 Group 1, Class B
Degree of explosion protection
Use in flammable environment
prohibited!
IP safety class IP20
