UNITY MOTORHOME MOTORHOME OPERATION
53
ᘐ CAUTION
If you have unplugged the motor electrical
connectors (
3
&
4
) from the control module
2
, do NOT move the motorhome unless the
slide out room and the slide out room motors
electrical connectors (
3
&
4
) are reconnected
to the control module .
2
Reconnecting the motor
electrical connectors to the control module
applies a brake to the slide out room motors,
keeping the slide out room locked in position.
4.
Unplug the microwave cord
5
in the cabinet
adjacent to microwave.
5
5. Remove the six screws
6
holding the microwave
in place.
666666
6. Remove the microwave.
7.
Remove foil
7
covering the access panel on the
right side.
7
8.
Remove the access panel
8
by removing the
staples first.
8
9. Remove the mounting screws
9
9
10. Locate the mounting screw on the ride side of the
slide out and remove the screw.
