MOTORHOME OPERATION UNITY MOTORHOME
54
11.
Peel back the exterior sweep gasket
10
from the
top corners of the slide out, and lift the slide out
motor approximately ½” to release.
10
12. Push in the slide out room until fully retracted,
keeping both sides of the slide out level with the
coach while retracting.
NOTE: Manual movement of the slide out requires
significant effort and may require the assistance of
several people.
13.
Peel back the exterior sweep gasket
10
from the
top corners of the slide out, and reengage the slide
out motor.
14.
Replace the motor mounting screw
9
on each side
of the slide out, and replace the microwave.
15. Reconnect both electrical connectors (
3
&
4
) to
the control module
2
.
16.
Install the travel lock before moving the motorhome.
ACCESSING THE MOTOR WHEN SLIDE OUT IS
OUT
1.
Turn the battery disconnect switch to the “OFF”
position, and disconnect the shore power. Refer
to the “Battery Disconnect Switch” section in the
“Electrical System Operation” section.
2.
Locate the control module
2
(installed in lower
galley.)
2
3
4
3. Unplug both motor electrical connectors (
3
&
4
) from the control module
2
.
 ᘐ CAUTION
If you have unplugged the motor electrical
connectors (
3
&
4
) from the control module
2
, do NOT move the motorhome unless the
slide out room and the slide out room motors
electrical connectors (
3
&
4
) are reconnected
to the control module
2
. Reconnecting the motor
electrical connectors to the control module
applies a brake to the slide out room motors,
keeping the slide out room locked in position.
