Adjusting the input signal
Setting the input signal of a digital unit is particularly important, much more than with an analog unit, as
any saturation of the A/D converters caused by excessively high input signals cause a typical particu-
larly distinct noise (high level square wave).
Proceed as follows:
+ Keep the DX 26 PLUS outputs in MUTE status (LEDs lit).
+ Feed a signal in on the DX 26’s input and watch the INPUT LEVEL A-B LED ladders.
To obtain a good signal/noise ratio, i.e. an up-front distortion-free signal, keep the signal quite high, but
make certain the red CLIP LED doesn’t light up continually.
+ First of all, find the output level setting for your mixer (or other unit) connected to the input of the DX 26
PLUS
+ Then adjust the DX 26 PLUS input gain if necessary:
Press the MODE key until the EDIT menu LED lights up.
Use the PREV and NEXT keys to go to the Input Gain page:
´
In
p
ut Gain
Press ENTER. The display shows the INA Gain or INA&B Gain page (according to the configuration
and other utilities loaded in the memory):
IN
A
G
A
IN
0.0dB
IN
A
&
BG
A
IN
0.0dB
Use the DIAL to change the gain value and watch the level of the signal on the LED ladders until the
ideal values are reached.
IN
A
G
A
IN
-2.5dB
IN
A
&
BG
A
IN
+6.0dB
Then use the PREV and NEXT keys to access the INB Gain page (if there is one – this depends on the
configuration and the other utilities loaded in the memory).
Repeat the settings as explained above.
