LEM DX 26 PLUS - Gain

33
Gain
Allows to control the boost or cut of the selected frequencies.
It’s not used with the Notch Filter, which has a fixed cut.
INA EQ1 Peak
2k00 1.0 -5.0
Peaking Low Shelving High Shelving
-20 dB
-15 dB
-10 dB
-5 dB
0 dB
5 dB
10 dB
15 dB
20 dB
10 Hz 100 Hz 1.000 Hz 10.000 Hz 100.000 Hz
-20 dB
-15 dB
-10 dB
-5 dB
0 dB
5 dB
10 dB
15 dB
20 dB
10 Hz 100 Hz 1.000 Hz 10.000 Hz 100.000 Hz
-20 dB
-15 dB
-10 dB
-5 dB
0 dB
5 dB
10 dB
15 dB
20 dB
10 Hz 100 Hz 1.000 Hz 10.000 Hz 100.000 Hz
The values can be set in the following ranges:
NAME TYPE GAIN FREQ WIDTH
Peak Peaking 0.05 ÷ 3.00 oct
(step 0.05 oct)
LoSh 6 Low Shelving 6dB/oct
LoSh 12 Low Shelving 12dB/oct
HiSh 6 High Shelving 6dB/oct
HiSh 12 High Shelving 12dB/oct
Notch Notch Filter - 45dB
(fix)
0.05 ÷ 3.00 oct
(step 0.05 oct)
5-BAND FULL PARAMETRIC EQ
±15dB
(step 0.5dB)
15.6Hz ÷ 16kHz
EDIT menu
