23
Load PRESET
This menu page allows the required PRESET to be loaded and made operative.
Load Preset
2U 2x2
X
To load a PRESET:
☞ Use the DIAL to reach the required PRESET.
21 Factory PRESETS, 64 User PRESETS and 128 Card User PRESETS are available.
N.B.: since the system must always be configured, there are no empty memory areas. All the User and Card areas
not yet used by custom PRESETS are automatically occupied by the *Default* PRESET, which contains a standard
start configuration with all the values of the various parameters at zero.
Load Preset
64U *Default*
135 B246
64U *Default*
Scrolling through the 128 memory areas reserved for the Card when the Multimedia Memory Card isn’t
inserted, the display shows the following message:
Load Preset
128C NO C
RD
☞ Press ENTER.
The system returns to default status and the display shows the information on the PRESET that has just
been loaded.
N.B.: in the example, Factory PRESET #3, named “2x3W” has been loaded: its system configuration is Input A signal
assigned to outputs 1, 3 and 5; Input B signal assigned to outputs 2, 4 and 6.
Loading a PRESET, a PRESET Change command is also automatically sent to the serial ports and can
be used to automatically load a PRESET with the same number to any other DX 26 PLUS units con-
nected and enabled (see UTILITY menu - Comm. Setup submenu - PRESET Change RX option).
PRESET menu
