LEM DX 26 PLUS - Input Delay

27
Input Delay
This menu page allows to adjust the delay lines of Input A, Input B and SUM.
´
In
p
ut Dela
y
The values can be set in the following ranges:
IN
A
DEL
A
Y
77ms
unit step
m0.0÷900.0 0.5
mm 0 ÷ 900000 7
ms 0 ÷ 2621 1
us 0 ÷ 2621438 21
range
INPUT DELAY
The measurement unit can be chosen with the function Delay Unit (UTILITY menu - Units submenu).
INPUT DELAY
INPUT A
MAIN PA
91ms - 31,5m (20°C)
INB DELAY = 91msINA DELAY = 0
INPUT B
DELAYED
DELAY Menu
