Introduction
Congratulations for having chosen the DX 26 PLUS!
DX 26 PLUS is an extremely versatile digital processor for loudspeaker systems
based on the GENERALMUSIC custom DSP RED 208. This powerful 40 bit resolution
DSP, together with low-noise 24 bit converters, provides an extremely high processing
quality and a dynamics suitable for the most professional applications.
DX 26 PLUS has 2 inputs (analog or digital) and 6 independent outputs and
can be configured as 2 or 3-way stereo, 2, 3, 4, 5 and 6-way mono or as distribution mixer with up
to 6 outputs. Configurations that allows the 2 input signals to be summed and routed to different outputs
are also available
Each of the 2 inputs has:
- MASTER DELAY, available also on the input SUM;
- digital NOISE GATE;
- 5-BAND PARAMETRIC EQ;
- level control.
Each of the 6 outputs has:
- DELAY line;
- 5-BAND PARAMETRIC EQ;
- CROSSOVER HP and LP filters which can be selected from the BESSEL, BUTTERWORTH and
LINKWITZ-RILEY types with slopes up to 48dB;
- phase control with 5° steps through a full 360°;
- digital COMPRESSOR/LIMITER;
- level and MUTE control.
All settings can be stored and recalled in an instant. In fact, the system has:
- 21 Factory PRESETS, each of which can be used as a basic configuration for preparing custom
PRESETS, others already optimized for LEM loudspeaker systems.
- 64 User PRESETS, which can be freely programmed to store all the system settings.
- 128 Card PRESETS, in fact User PRESETS that can be stored on Multimedia Memory Cards.
Each User or Card PRESET can contain any of the Input/Output configurations available.
All operations are carried out via user interface that includes a 2x16 LCD, a convenient DIAL for
the parameter modification and selector buttons for the direct access to all the features. DX 26 PLUS is
also equipped with 2 types of serial interface (RS232 and RS485) for the remote control thru a PC and
for the linking of more units.
