Technical Specifications
Connectors 2 x COMBO
Nominal input sensitivity 0 dB (0.775 V)
Input Impedance 30kOhm, electronically balanced
Maximum Input Level +20dBu
Input Gain -30 / +6 dB variable in 0.5 dB steps
Digital input AES/EBU, XLR-F
Digital input sample rate 32 kHz ÷ 48 kHz
Connectors 6 x XLR-M
Output Impedance 600 Ohms, electronically balanced
Nominal Output Level 0 dBu
Maximum Output Level +20 dBu
Output Gain -30 / +6 dB variable in 0.5 dB steps
A/D converters 24 bit
D/A converters 24 bit
Internal dynamics 40 bit
Sampling frequency 48 kHz
Configuration 2-WAY STEREO, 3-WAY STEREO, 2,3,4,5,6-WAY MONO
Crossover Filters Type Bessel, Butterworth or Linkwitz-Riley
Crossover Filters Slope 6, 12, 18, 24, or 48dB per octave
Delay Step 21 microseconds minimum
Max Delay time 2621 ms (inputs), 291 ms (outputs)
EQ filters Up to 40 maximum (depending on the crossover slope)
EQ Type Peak, 6dB Lo-Shelf, 12dB Lo-Shelf, 6dB Hi-Shelf, 12dB Lo-Shelf, Notch
EQ Gain +/15dB, variable in 0.5dB steps
EQ Bandwidth 0.05 to 3.00 octaves, variable in 0.05 steps
EQ freq 15.6 Hz to 16 kHz
Dynamics Compressor/Limiter on the outputs - Noise Gate on the inputs
Memories 21 FACTORY PRESETS + 64 USER PRESETS + 128 CARD PRESETS
Communications 9-pin RS232, XLR-F RS485 IN, XLR-F RS485 IN
Frequency Response 20Hz - 20kHz, ±0.25dB
Dynamic range
>117dB 20Hz to 20kHz
>120dB 20Hz to 20kHz on AES/EBU input
Channel Separation >100dB 20Hz to 20kHz
Distortion (THD) 0.05%, 20Hz to 20kHz
Input Metering -24dB, -18dB, -12dB, -6dB, CLIP relative to Clip point (+20dBu)
Output Metering -24dB, -12dB, -6dB, LIMIT relative to limiter threshold setting, CLIP
Dimensions 483x44x300 mm
Weight 4.0 Kg
Power supply see label on the unit
