This also affects the number and contents of the editing pages on each occasion.
For example, the INPUT DELAY editing pages can have the following variations:
INPUT
GANGING
PAGES
OFF 3 INA Delay INB Delay SUM Delay
ON 2INA&B Delay SUM Delay
OFF 2 INA Delay INB Delay
ON 1INA&B Delay
OFF 2 INA Delay SUM Delay
ON 2INA Delay SUM Delay
OFF 3 INA Delay INB Delay SUM Delay
ON 3INA Delay INB Delay SUM Delay
OFF 2 INA Delay SUM Delay
ON 2INA Delay SUM Delay
OFF 3 INA Delay INB Delay SUM Delay
ON 3INA Delay INB Delay SUM Delay
OFF 1 INA Delay
ON 1INA Delay
OFF 2 INA Delay INB Delay
ON 2INA Delay INB Delay
PARAMETERSCONFIGURATION
DX 26 PLUS - INPUT DELAY EDITING PAGES
A13 B24 S56
A135 B246
A1234 S56
A123 B4 S56
A12345 S6
A12345 B6
A1234 B5 S6
A123456
