9
RS485 IN & OUT
RS485 standard serial communication interface port.
Allows incoming and outgoing communication between a DX 26 PLUS and a PC or other DX 26
PLUS units.
The characteristics of the RS485 interface make these ports particularly suitable for remote control
over long distances (difficult with RS232 standard ports) and for daisy-chaining several DX 26 PLUS.
POWER
Unit’s ON/OFF switch.
Before switching on or off, make certain that the sound system’s amplifiers are off to avoid signal
peaks, which are annoying and sometimes dangerous.
AC ~
Connector for the power supply cable.
Before switching on the unit, make certain that the mains voltage matches that shown on the rear
(a tolerance of up to ±10% is acceptable). Before connecting or disconnecting the power cord,
make certain the ON/OFF switch is in the OFF position.
Rear Panel
