5.LocatetheiButtonsocketonthesystemboard.InsertonesideoftheTR100keyunderoneofthe
retainingclipsontheiButtonsocket.Then,carefullypresstheothersideoftheTR100keystraight
downuntilthekeysnapsintopositionandissecuredbythetworetainingclipsontheiButtonsocket.
Note:Ifnecessary,removeanypartsordisconnectanycablesthatmightimpedeyouroperation.
Figure53.InstallingtheTR100key
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage177.Then,theonboard
SATAsoftwareRAID5isavailableforyourserverifyourserverhastherequirednumberofharddisk
drivesinstalled.TocongureRAID,see“ConguringRAID”onpage73.
RemovingtheTR100key
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstandingthe“Safetyinformation”
onpageiiiand“Guidelines”onpage85.
ThistopicprovidesinstructionsonhowtoremovetheTR100key.
Notes:
1.ThistopicappliesonlytoserversthathaveaTR100keyoptioninstalled.
2.IfyouremovetheTR100key,theonboardSATAsoftwareRAID5willbedisabled.
Chapter6.Installing,removing,orreplacinghardware113
