Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:UseanydocumentationthatcomeswiththeTR100keyandfollowthoseinstructionsinadditionto
theinstructionsinthistopic.
ToremovetheTR100key,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage87.
3.Laytheserveronitssideforeasieroperation.
4.LocatetheiButtonsocketonthesystemboard.Opentheretainingclip1ontheiButtonsocketto
releasetheTR100keyandthencompletelyremovethekeyfromtheiButtonsocket.
Note:Ifnecessary,removeanypartsordisconnectanycablesthatmightimpedeyouroperation.
Figure54.RemovingtheTR100key
5.IfyouareinstructedtoreturntheoldTR100key,followallpackaginginstructionsanduseany
packagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
114ThinkServerTS430HardwareMaintenanceManual
