14.Forthenewsystemboard,gentlypressdownthesmallhandleonthemicroprocessorsocketand
thenpullthehandlealittlebitoutwardtoreleaseitfromthesecuredposition.Then,pivotthehandle
upwarduntilthehandleandthemicroprocessorretainerareinthefullyopenposition.Removethe
microprocessorsocketcoverfromthenewsystemboard.
Notes:
a.Yourmicroprocessorsocketandcovermightlookslightlydifferentfromtheillustration.
b.Donotdropanythingontothemicroprocessorsocketwhileitisexposed.Thesocketpinsmustbe
keptascleanaspossible.
Figure108.Removingthemicroprocessorsocketcover
15.Removethemicroprocessorfromtheoldsystemboardandinstallitdirectlyonthenewsystemboard.
See“Replacingthemicroprocessor”onpage166.
16.Theoldsystemboardmustbereturnedwithamicroprocessorsocketcovertoprotectthepinsonthe
socketduringshippingandhandling.Usethemicroprocessorsocketcoverremovedfromthenew
systemboard.Toinstallitontheoldsystemboard,dothefollowing:
a.Makesurethatthesmallhandleandthemicroprocessorretainerareinthefullyopenposition.
