6.Slidethenewopticaldriveintothedrivebayfromthefrontuntilitsnapsintoposition.
Note:Youdonotneedtoremovethefrontbezelwhenreplacinganopticaldrive.However,ifyouare
addingasecondaryopticaldriveintheupperopticaldrivebay,youneedtoremovethefrontbezelrst,
andthengainaccesstotheprotectiveshieldstoremovethem.Thefollowingillustrationshowsonlythe
situationinwhichthefrontbezelhasnotbeenremoved.
Figure47.Installingtheopticaldrive
7.Connectthepowercable1andthesignalcable2totherearofthenewopticaldrive.
Figure48.Connectingcablestotherearoftheopticaldrive
8.Ifnecessary,connecttheotherendofthesignalcabletotheappropriateSATAconnectoronthesystem
board.See“Systemboardcomponents”onpage37.
9.Reinstallthefrontbezelifyouhaveremovedit.See“Removingandreinstallingthefrontbezel”on
page67.
10.Dooneofthefollowing:
