Componentsofservermodelswithfour3.5-inchnon-hot-swapharddiskdrivebays
Figure13.Componentsofservermodelswithfour3.5-inchnon-hot-swapharddiskdrivebays
1Coverpresenceswitch
11Frontsystemfan2
2Powerconversionboard
12Systemboard
3Frontpanel
13Systemboardbattery
4Opticaldrivebay2(withanopticaldriveinstalled
insomemodels)
14Low-prolePCIcardbracket
5Opticaldrivebay1(withanopticaldriveinstalled)15MainPCIcardbracket
6Harddiskdrivebay316Expansioncard
7Harddiskdrivebay2
17Heatsinkandfanassembly
8Harddiskdrivebay1
18Rearsystemfan
9Harddiskdrivebay019Powersupply
10Frontsystemfan1
20Fourmemoryslots(installedmemorymodulesvaryby
model)
Note:Thepowerconversionboard2,low-prolePCIcardbracket14,andmainPCIcardbracket15are
availableinservermodelsthatcomewithaRAIDcard.
Hot-swapharddiskdrivestatusLEDs
Thistopicappliesonlytoservermodelswithhot-swapharddiskdrives.
26ThinkServerTS440UserGuide
