Componentsofservermodelswitheight2.5-inchhot-swapharddiskdrivebays
Figure12.Componentsofservermodelswitheight2.5-inchhot-swapharddiskdrivebays
1Coverpresenceswitch
13Harddiskdrivebay0
2Powerconversionboard
14Frontsystemfan1
3Frontpanel
15Frontsystemfan2
4Opticaldrivebay2(withanopticaldriveinstalled
insomemodels)
16Systemboard
5Opticaldrivebay1(withanopticaldriveinstalled)17Systemboardbattery
6Harddiskdrivebay7
18Low-prolePCIcardbracket
7Harddiskdrivebay6
19MainPCIcardbracket
8Harddiskdrivebay520Expansioncard
9Harddiskdrivebay4
21Heatsinkandfanassembly
10Harddiskdrivebay3
22Rearsystemfan
11Harddiskdrivebay223Powersupply
12Harddiskdrivebay1
24Fourmemoryslots(installedmemorymodulesvaryby
model)
Note:Thepowerconversionboard2,low-prolePCIcardbracket18,andmainPCIcardbracket19are
availableinservermodelsthatcomewithaRAIDcard.
Chapter3.Productoverview25
