ThinkServerRAID700Adapter(alsoknownasThinkServer9260-8iSASRAIDAdapter)
ThefollowingillustrationshowstheconnectorsontheThinkServerRAID700Adapter.
Figure17.ThinkServerRAID700Adapter
1Ports7-4
3ThinkServerRAID700Batteryconnector
2Ports3-0
1Ports7-4
Usedtoconnectamini-SASsignalcable.See“Connectingthecables”onpage34.
2Ports3-0
Usedtoconnectamini-SASsignalcable.See“Connectingthecables”onpage34.
3ThinkServerRAID700Batteryconnector
UsedtoconnectaThinkServerRAID700Battery.See“InstallingorremovingtheThinkServerRAID700
Battery”onpage86
.
Hot-swapharddiskdrivebackplane
Yourservermightcomewithoneofthefollowinghot-swapharddiskdriveandbackplanecongurations:
•Fivetoeight3.5-inchhot-swapSATAorSASharddiskdriveswithtwobackplanes
•Uptofour3.5-inchhot-swapSATAorSASharddiskdriveswithonebackplane
•Uptoeight2.5-inchhot-swapSASharddiskdriveswithonebackplane
