Lenovo ThinkServer TS440 - Front Panel

Frontpanel
Thistopicprovidesinformationtohelpyoulocatethecontrol,connectors,andLEDsonthefrontpanelof
theserver.
Thefollowingillustrationshowsthecontrol,connectors,andLEDsonthefrontpaneloftheserver.
Note:Dependingonthemodel,yourservermightlookslightlydifferentfromthefollowingillustration.
Figure4.Frontpanel
1PowerbuttonwithpowerstatusLED
4FrontUSB3.0connector1
2HarddiskdrivestatusLED
5FrontUSB3.0connector2
3NetworkInterfaceController(NIC)statusLED
1PowerbuttonwithpowerstatusLED
Pressthepowerbuttontoturnontheserverwhenyounishsettinguptheserver.Youalsocanholdthe
powerbuttonforseveralsecondstoturnofftheserverifyoucannotturnofftheserverfromtheoperating
system.SeeChapter4“Turningonandturningofftheserver”onpage43.ThepowerstatusLEDhelpsyou
todeterminethecurrentpowerstatus.
Chapter3.Productoverview15
