Lenovo ThinkServer TS440 - Front View of the Server

Frontviewoftheserver
Thistopicprovidesinformationtohelpyoulocatethepartsonthefrontoftheserver.
Thefollowingillustrationshowsthefrontviewoftheserver.
Figure3.Frontviewoftheserver
1Frontpanel
5OpticaldrivestatusLED
2Opticaldrivebay2(withanopticaldriveinstalled
insomemodels)
6Frontdoor
3Opticaldrivebay1(withanopticaldriveinstalled)
7Frontdoorlock
4Opticaldriveeject/closebutton
8Frontdoorhandle
1Frontpanel
Fordetailedinformationaboutthecontrol,connectors,andstatusLEDsonthefrontpanel,see“Front
panel”onpage15.
2Opticaldrivebay2
The5.25-inchopticaldrivebay2isforasecondaryopticaldrive.Somemodelshaveasecondaryoptical
driveinstalled.
3Opticaldrivebay1
Yourservercomeswithanopticaldriveinstalledinthe5.25-inchopticaldrivebay1.
Chapter3.Productoverview13
