10.AlignthetopedgeoftheEMI-protectivepanelwiththetopsideoftheharddiskdrivecage,andthen
pivottheEMI-protectivepaneldownuntilitsnapsintoposition.
Figure57.InstallingtheEMI-protectivepanel
11.DisconnecttheSATAcablefortheremovednon-hot-swapharddiskdrivefromthesystemboardand
savethecableforfutureuse.
12.Closeandlockthefrontdoor.
13.Ifyouareinstructedtoreturntheoldnon-hot-swapharddiskdrive,followallpackaginginstructionsand
useanypackagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheremovalprocedure,goto“Completingthepartsreplacement”onpage141
.Then,you
mightneedtorecongureRAIDforyourserver.See“ConguringRAID”onpage55.
Installingorreplacingahot-swapharddiskdrive
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage63.
Thistopicprovidesinstructionsonhowtoinstallorreplaceahot-swapharddiskdrive.
Thistopicappliesonlytoservermodelsthathavehot-swapharddiskdrivesinstalled.See“Features”on
page7
formoreinformationaboutthesupportedhot-swapharddiskdrives.
ForalistofThinkServerharddiskdriveoptions,goto:
http://www.lenovo.com/thinkserver
