Lenovo ThinkServer TS440 - Replacing the Front Panel Board Assembly

9.Insertthetab1onthecoverpresenceswitchframeintothecorrespondingholeinthechassisuntil
theframeissecurelyseated.Ensurethatthescrewholeinthecoverpresenceswitchframeisaligned
withthecorrespondingscrewholeinthechassis.Theninstallthescrewtosecurethecoverpresence
switchassemblytothechassis.
Figure81.Installingthecoverpresenceswitchassembly
10.Connectthecableofthenewcoverpresenceswitchtothesystemboard.See“Systemboard
components”onpage37
.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage141.
Replacingthefrontpanelboardassembly
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage63.
Thistopicprovidesinstructionsonhowtoreplacethefrontpanelboardassembly.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
126ThinkServerTS440UserGuide
