Lenovo ThinkServer TS440 User Manual

4.Notetheorientationofthehot-swapredundantpowersupply,andthenslideitintothechassisuntil
itsnapsintoposition.
Figure64.Installingahot-swapredundantpowersupply
5.Connectthepowercordtothepowercordconnectoronthenewhot-swapredundantpowersupply.
Then,checkthestatusLEDnearthepowercordconnector.WhentheLEDislitingreen,itindicates
thatthehot-swapredundantpowersupplyisworkingcorrectly.WhentheLEDislitinamber,itindicates
thatthehot-swapredundantpowersupplyislikelytofailorhasfailed.Reinstallthenewhot-swap
redundantpowersupplytoseeiftheproblemcanbesolved.Ifthenewhot-swapredundantpower
supplystilldoesnotworkcorrectly,contactyourplaceofpurchaseoraservicerepresentativeforhelp.
6.Ifyouareinstructedtoreturntheoldhot-swapredundantpowersupply,followallpackaginginstructions
anduseanypackagingmaterialsthataresuppliedtoyouforshipping.
Replacingthepowerdistributionboardandcageassembly
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage63.
Thistopicprovidesinstructionsonhowtoreplacethepowerdistributionboardandcageassembly.This
topicappliesonlytoservermodelsthatcomewithhot-swapredundantpowersupplies.
CAUTION:
Hazardousmovingparts.Keepngersandotherbodypartsaway.
110ThinkServerTS440UserGuide

Lenovo ThinkServer TS440 Specifications

General

Chipset	Intel C226
Memory Slots	4 DIMM slots
Network Interface	Dual Gigabit Ethernet
Form Factor	Tower
Processor	Intel Xeon E3-1200 v3, Intel Core i3, Intel Pentium
Storage Bays	4 x 3.5" hot-swap bays
RAID Support	RAID 0, 1, 5, 10
Power Supply	450W
Expansion Slots	1 x PCIe 3.0 x16, 1 x PCIe 2.0 x4
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere
