CAUTION:
Hazardousmovingparts.Keepngersandotherbodypartsaway.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
Toreplacethefrontsystemfan1,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage65.
3.Locatethefrontsystemfan1.See“Servercomponents”onpage22.
4.Disconnectthefrontsystemfan1cablefromthesystemfan1connectoronthesystemboard.See
“Systemboardcomponents”onpage37.
5.Pressthetwotabsofthefrontsystemfan1towardseachotheruntilthetwotips1arealignedwiththe
correspondingholesinthechassis.Then,carefullyslidethefrontsystemfan1outofthechassis.
Figure84.Removingthefrontsystemfan1
6.Touchthestatic-protectivepackagethatcontainsthenewfrontsystemfan1toanyunpaintedsurface
ontheoutsideoftheserver.Then,removethenewfrontsystemfan1fromthepackage.
Chapter6.Installing,removing,orreplacinghardware129
