9.Notetheorientationofthenewmicroprocessor.Holdthenewmicroprocessorbyitsedgesandalign
thenotches1onitwiththetabs2inthemicroprocessorsocket.Then,carefullylowerthenew
microprocessorstraightdownintothemicroprocessorsocket.
Note:Thesmalltriangle3ononecornerofthenewmicroprocessoristhemicroprocessororientation
indicator.Thenewmicroprocessorisinthecorrectorientationwhenthisindicatorfacesthebeveled
corner
4ofthemicroprocessorsocket.
Figure93.Installingthemicroprocessor
10.Gentlyclosethemicroprocessorretainer,pressdownthesmallhandle,andthenpushthehandleinward
tolocktheretainerintopositionandsecurethenewmicroprocessorinthesocket.
Figure94.Securingthemicroprocessorinthesocket
11.Reinstalltheheatsinkandfanassembly.See“Replacingtheheatsinkandfanassembly”onpage132.
12.Ifyouareinstructedtoreturntheoldmicroprocessor,followallpackaginginstructionsanduseany
packagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage141.
