Componentsofservermodelswithfour3.5-inchhot-swapharddiskdrivebays
Figure10.Componentsofservermodelswithfour3.5-inchhot-swapharddiskdrivebays
1Coverpresenceswitch
11Frontsystemfan2
2Powerconversionboard
12Systemboard
3Frontpanel
13Low-prolePCIcardbracket
4Opticaldrivebay2(withanopticaldriveinstalled
insomemodels)
14MainPCIcardbracket
5Opticaldrivebay1(withanopticaldriveinstalled)15Systemboardbattery
6Harddiskdrivebay316Expansioncard
7Harddiskdrivebay2
17Heatsinkandfanassembly
8Harddiskdrivebay1
18Rearsystemfan
9Harddiskdrivebay019Powersupply
10Frontsystemfan1
20Fourmemoryslots(installedmemorymodulesvaryby
model)
Note:Thepowerconversionboard2,low-prolePCIcardbracket13,andmainPCIcardbracket14are
availableinservermodelsthatcomewithaRAIDcard.
Chapter3.Productoverview23
