Lenovo ThinkServer TS440 - Page 50

31
33
32
Figure25.Systemboardcomponents
14-pinpowerconnector
18SATAconnector2
2Systemboardbattery19Systemfan1connector
3Microprocessorsocket20Frontpanelconnector
4Microprocessorfanconnector
21FrontUSB3.0connector
5Memoryslot1(DIMM1)22PlatformControllerHub(PCH)
6Memoryslot2(DIMM2)23SATASGPIOconnector
7Memoryslot3(DIMM3)24USB2.0connector
8Memoryslot4(DIMM4)25ClearCMOS(ComplementaryMetalOxideSemiconductor)
jumper
9Thermalsensorconnector
26ManagementEngine(ME)disablejumper
10Systemfan2connector27Serialconnector
114-pinpowerconnector
28PCIcardslot(PCIslot4)
124-pinpowerconnector
29PCIExpressx4cardslot(PCI-Eslot3)
13Mainpowerconnector
30PCIExpressx1cardslot(PCI-Eslot2)
14SATAconnector331PCIExpressx16cardslot(PCI-Eslot1)
15SATAconnector0
32Rearsystemfanconnector
16SATAconnector433Coverpresenceswitchconnector(intrusionswitchconnector)
17SATAconnector1
38ThinkServerTS440UserGuide
