8.LocatetheTR500keyconnectorontheThinkServerRAID500Adapterandthencarefullyinsertthe
TR500keyintotheconnector.Ifnecessary,youcanremovetheThinkServerRAID500Adapterrst,
installtheTR500Keyonit,andthenreinstalltheThinkServerRAID500Adapter.See“Installingor
removingtheRAIDcard”onpage80
.
Note:EnsurethattheTR500keyissecurelyseatedontheThinkServerRAID500Adapter.
Figure41.InstallingtheTR500key
9.Reinstallanypartsorreconnectanycablesthatyouhaveremoved.
10.ReinstallthePCIcardbracketassembly.See“RemovingandreinstallingthePCIcardbracket
assembly”onpage69
.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage141
.Then,thehardware
RAID5andRAID50levelsareavailableforyourserverifyourserverhastherequirednumberofharddisk
drivesinstalled.ForinformationabouthowtocongurethehardwareRAID,refertotheMegaRAIDSAS
SoftwareUserGuideonthedocumentationDVDthatcomeswithyourserver.
RemovingtheTR500Key
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage63.
ThistopicprovidesinstructionsonhowtoremovetheTR500KeyifyourserverhasaThinkServerRAID
500AdapterwithaTR500Keyoptioninstalled.
Attention:BackupyourdatabeforeyoubeginifyouneedtorecongureRAIDandreinstalltheoperating
systemafterremovingtheTR500Key.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•IfyouremovetheTR500KeyfromtheThinkServerRAID500Adapter,thehardwareRAID5andRAID50
levelswillbedisabled.
