3.Locatethefrontpanelboardassemblyanddisconnectcablesfromthesystemboard.See“Server
components”onpage22
.
4.Pressthereleasetabinthedirectionasshownandpivotthefrontpanelboardassemblyoutward.Pull
thecablesouttocompletelyremovethefrontpanelboardassemblyfromthechassis.
2
1
Figure60.Removingthefrontpanelboardassembly
5.Disconnectcablesfromthefrontpanelboardassembly.Then,installanewfrontpanelboardassembly.
See“Installingthefrontpanelboardassembly”onpage89.
6.Ifyouareinstructedtoreturntheoldfrontpanelboardassembly,followallpackaginginstructionsand
useanypackagingmaterialsthataresuppliedtoyouforshipping.
Installingthefrontpanelboardassembly
Toinstallthefrontpanelboardassembly,dothefollowing:
1.Prepareyourserverandremovetheservercover.See“Preparingyourserverinadvanceandremoving
theservercover”onpage57.
2.Removethefrontbezel.See“Removingthefrontbezel”onpage59.
3.Connectcablestothenewfrontpanelboardassemblyandroutecablesthroughthecorresponding
holeinthechassis.
Chapter5.Replacinghardware89
