3 NVMEM discharge LED
The NVMEM discharge LED provides the status of ONTAP running on the controller.
Status Color
Description
Blinking
Green
NVMEM destage events are occurring.
Solid Green NVMEM destage events completed successfully.
Off
None The system is running normally and the NVMEM is
ready if ONTAP is running.
4 Controller location LED
The controller location LED is a blue LED that helps to show the location of a specific controller in a system.
5 Controller attention LED
The controller attention LED indicates that there is an issue with a controller. Check other LEDs and event
logs to determine the cause of the issue.
Status Color
Description
On
Amber The controller has a fault.
Off None The controller is operating normally.
6 Controller activity LED
The controller activity LED provides the status of ONTAP running on the controller.
Status Color
Description
Blinking
Green The controller is running ONTAP. The length of time the
light remains on is proportional to the controller activity.
Off
None
ONTAP is not running on the controller.
7 8 10 Gb Ethernet RJ45 port status LEDs
The Ethernet port has two status LEDs.
Status LED Status Color Description
7 10 GbE port link LEDs (2) On Green
A connection is established between the port
and some upstream devices.
Off
None No connection is established on the port.
8 10 GbE port activity LEDs
(2)
Blinking Green Traffic is flowing over the connection.
Off
None No traffic is flowing over the connection.
9 10 25 Gb Ethernet port status LEDs
The Ethernet port has two status LEDs.
Status LED Status Color
Description
9 25 GbE port link LEDs (2) On Green
A connection is established on the port.
Off
None No connection is established on the port.
Chapter 2. System components 9
