Install the middle or rear 3.5-inch-drive backplane
Use this information to install the middle or rear 3.5-inch-drive backplane.
About this task
Your server supports:
• One type of middle 3.5-inch-drive backplane
– 4 x 3.5-inch SAS/SATA backplane
• Two types of rear 3.5-inch-drive backplane
– 2 x 3.5-inch SAS/SATA backplane
– 4 x 3.5-inch SAS/SATA backplane
Notes:
• The procedure shows the installation of the backplane on the rear drive cage. The procedure is the same
for installing the backplane on the middle drive cage.
Attention:
• Read “Installation Guidelines” on page 129 to ensure that you work safely.
• Prevent exposure to static electricity, which might lead to system halt and loss of data, by keeping static-
sensitive components in their static-protective packages until installation, and handling these devices with
an electrostatic-discharge wrist strap or other grounding system.
A video for this task is available at:
• Youtube:
https://www.youtube.com/playlist?list=PLYV5R7hVcs-Bz2XIeLEfGcrLGm9TSY_yt
• Youku: http://list.youku.com/albumlist/show/id_52339612.html
Chapter 4. Hardware replacement procedures 201
