Remove the 7mm drive cage
Use this information to remove the 7mm drive backplane.
About this task
The following illustrates how to remove the 7mm rear drive assembly from a riser cage assembly(two full-
height slots + one 7mm cage). The single-slot 7mm rear drive assembly is directly installed on the chassis
and can be removed the same way as that for riser 1/2 assembly.
Attention:
• Read “Installation Guidelines” on page 129 to ensure that you work safely.
• Power off the server and disconnect all power cords for this task.
• Prevent exposure to static electricity, which might lead to system halt and loss of data, by keeping static-
sensitive components in their static-protective packages until installation, and handling these devices with
an electrostatic-discharge wrist strap or other grounding system.
A video for this task is available at:
• Youtube:
https://www.youtube.com/playlist?list=PLYV5R7hVcs-Bz2XIeLEfGcrLGm9TSY_yt
• Youku: http://list.youku.com/albumlist/show/id_52339612.html
338 ThinkSystem SR665 Maintenance Manual
