Chapter 2. Server components
This section provides information to help you locate your server components.
Front view
The front view of the server varies by model. Depending on the model, your server might look slightly
different from the illustrations in this topic.
Refer to the following front view for different server models:
• Server models with 2.5-inch front drive bays
–
“Eight 2.5-inch front drive bays” on page 12
– “Eight 2.5-inch front drive bays (with LCD diagnostics panel)” on page 13
– “Sixteen 2.5-inch front drive bays” on page 14
– “Sixteen 2.5-inch front drive bays (with LCD diagnostics panel)” on page 15
– “Twenty-four 2.5-inch front drive bays” on page 16
– “Backplane-less” on page 17
• Server models with 3.5-inch front drive bays
–
“Eight 3.5-inch front drive bays” on page 18
– “Twelve 3.5-inch front drive bays” on page 19
– “Backplane-less” on page 20
© Copyright Lenovo 2019 11
