10 Parameter reference
10.2 Parameter list | C00120
253
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00120
C00122
C00123
C00134
Parameter | Name:
C00120 | Motor overload threshold (I²xt)
Data type: INTEGER_16
Index: 24455
d
= 5F87
h
Operating threshold for the error message "OC6: Motor overload (I²xt)"
• The response for reaching the threshold can be selected in C00606
.
• The current thermal motor load is displayed in C00066
.
Motor overload monitoring (I2xt)
Setting range (min. value | unit | max. value) Lenze setting
0 % 250 100 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00122 | Initial value motor overload (I²xt)
Data type: UNSIGNED_16
Index: 24453
d
= 5F85
h
From version 03.04.00
The thermal motor load displayed in C00066
is pre-initialised with the value set here when the device is connected
to the mains.
• If "100.00 %" is set, the last value at switching off the device is used for the initialisation.
• Recommended setting for operation according to UL: 50.00 %
Motor overload monitoring (I2xt)
Setting range (min. value | unit | max. value)
0.00 % 100.00
Subcodes Lenze setting Info
C00122/1 0.00 % Initial value motor overload (I²xt)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00123 | Device utilisation threshold (Ixt)
Data type: INTEGER_16
Index: 24452
d
= 5F84
h
Operating threshold for the error message "OC5: Device overload (Ixt)"
• The response for reaching the threshold can be selected in C00604
.
• The current device utilisation is displayed in C00064
.
Setting range (min. value | unit | max. value) Lenze setting
0 % 100 100 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00134 | Ramp smoothing, main setpoint
Data type: UNSIGNED_8
Index: 24441
d
= 5F79
h
FB L_NSet_1: Configuration of the ramp smoothing for the main setpoint
Selection list (Lenze setting printed in bold) Info
0Off Ramp rounding deactivated
1 PT1 behaviour Ramp rounding with PT1 behaviour
• The corresponding S-ramp time must be set in
C00182
.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
