10 Parameter reference
10.2 Parameter list | C00620
285
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00620
Parameter | Name:
C00620 | 16-bit system connection
Data type: UNSIGNED_16
Index: 23955
d
= 5D93
h
Connection parameters: 16-bit inputs
• Selection of the 16-bit output signals for connection with the 16-bit input signals.
• The selection list contains all 16-bit output signals which can be assigned to the 16-bit inputs mapped by the
subcodes.
Selection list
See selection list - analog signals
Subcodes Lenze setting Info
C00620/1 0: Not connected Reserved
C00620/2 0: Not connected Reserved
C00620/3 0: Not connected Reserved
C00620/4 0: Not connected Reserved
C00620/5 0: Not connected LS_DisFree
:wDis1
C00620/6 0: Not connected LS_DisFree
:wDis2
C00620/7 0: Not connected LS_DisFree
:wDis3
C00620/8 0: Not connected LS_DisFree
:wDis4
C00620/9 0: Not connected LS_DisFree_a
:nDis1_a
C00620/10 0: Not connected LS_DisFree_a
:nDis2_a
C00620/11 0: Not connected LS_DisFree_a
:nDis3_a
C00620/12 0: Not connected LS_DisFree_a
:nDis4_a
C00620/13 0: Not connected Reserved
C00620/14 0: Not connected Reserved
C00620/15 0: Not connected Reserved
C00620/16 0: Not connected Reserved
C00620/17 0: Not connected Reserved
C00620/18 0: Not connected Reserved
C00620/19 0: Not connected Reserved
C00620/20 0: Not connected LP_CanOut1
: wState
C00620/21 0: Not connected LP_CanOut1: wOut2
C00620/22 0: Not connected LP_CanOut1
: wOut3
C00620/23 0: Not connected LP_CanOut1
: wOut4
C00620/24 0: Not connected LP_CanOut2: wOut1
C00620/25 0: Not connected LP_CanOut2
: wOut2
C00620/26 0: Not connected LP_CanOut2
: wOut3
C00620/27 0: Not connected LP_CanOut2
: wOut4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
