Parameter setting with the E82ZBC keypad
Transfer parameters to other controllers
9
Parameter setting
9.3
9.3.5
L
9.3-6
EDS82EV903-1.0-11/2002
9.3.5 Transfer parameters to other controllers
The keypad enables you to easily copy parameter settings from one controller to
another.
Step Keys Result Action
1. Connect the keypad to controller 1
g
xx.xx
Hz
Function g is activated. The first code in the
user me nu will be displayed (C0517/1, Lenze
setting: C0050 = output f r equency).
2. Inhibit controller
s dc
The drive is idling
3. Select C0002 in the user menu
x f
4.
z 0002
Select C0002
5.
x i
6. Select the correct copy function The settings stored in the keypad are
overwritten.
• Copying all parameter sets available (PAR1 ... PAR4, ggf. FPAR1) to the keypad:
– Controller with function module
application I/O, INTERBUS,
PROFIBUS-DP, LECOM-B,
DeviceNet/CANopen
z 80
Copy PAR1 ... PAR4 und FPAR1:
ð Set ”80”
– Controller with all other
function modules
z 20
Copy PAR1 ... PAR4:
ð Set ”20”
• Copying only the module-specific parameter set FPAR1 to the keypad:
– Only possible for controllers
with function module
INTERBUS, PROFIBUS-DP,
LECOM-B, DeviceNet/CANopen:
z 50
Copy FPAR1:
ð Set ”50”
7. Start copying
v STOre
SaUe
The selected parameter sets are copied to the
keypad.
If
SaUe stops, the copy process is completed.
8. Enable the controller.
u
The drive should be running again
Copying parameter sets from the
controller to the keypad
