Free connection of digital signals
Free configuration of digital input signals
10
Function library
10.13
10.13.1
L
10.13-2
EDS82EV903-1.0-11/2002
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0410
v
Free configuration
of digital input
signals
Link between digital signal sources and internal digital
signals
A selection made under C0007 is copied
to the corresponding s ubcode of C0410.
A change of C0410 sets C0007 = 255!
^
10.13-1
1 NSET1-JOG1/3
NSET1-JOG1/3/5/7
(A)
1 Digital input X3/E1
Selection of fixed setpoints
C0410/1 C0410/2
C0410/33
LOW LOW LOW
active
C0046
JOG1
2 NSET1-JOG2/3
NSET1-JOG2/3/6/7
(A)
2 Digital input X3/E2
L
O
W
L
O
W
L
O
W
HIGH LOW LOW
LOW HIGH LOW
... ... ...
HIGH HIGH HIGH
J
O
G
1
JOG2
...
JOG7
3 DCTRL1-CW/CCW 4 Digital input X3/E4 CW = CW rotation
CCW = CCW rotation
LOW
HIGH
4 DCTRL1-QSP 255 Not assigned (FIXED-FREE) Quickstop(viaterminalLOWactive)
5 NSET1-RFG1-STOP 255 Not assigned (FIXED-FREE) Ramp function generator main setpoint stop
6 NSET1-RFG1-0 255 Not assigned (FIXED-FREE) Ramp function generator input must be set
to”0”formainssetpoint
7 MPOT1-UP 255 Not assigned (FIXED-FREE)
Motor potentiometer functions
8 MPOT1-DOWN 255 Not assigned (FIXED-FREE)
p
9 Reserved 255 Not assigned (FIXED-FREE) Do not change 255!
10 DCTRL1-CINH 255 Not assigned (FIXED-FREE) Controller inhibit (via terminal LOW active)
11 DCTRL1-TRIP-SET 255 Not assigned (FIXED-FREE) External error (via terminal LOW active)
12 DCTRL1-TRIP-RESE
T
255 Not assigned (FIXED-FREE) Error reset
13 DCTRL1-PAR2/4 255 Not assigned (FIXED-FREE) Parameter set changeover
(only possible if C0988 = 0)
C0410/13 and C0410/14 must have th e
same source in every parameter sets
used. Otherwise it is not p ossible to
change between the parameter sets
(errormessageCE5orCE7).
14 DCTRL1-PAR3/4 255 Not assigned (FIXED-FREE) C0410/13 C0410/14
LOW LOW
HIGH LOW
LOW HIGH
HIGH HIGH
active
PAR1
PAR2
PAR3
PAR4
15 MCTRL1-DCB 3 Digital input X3/E3 DC-injection brake
16
(A)
PCTRL1-RFG2-
LOADI
255 Not assigned (FIXED-FREE) Actual process controller value
(PCTRL1-ACT) must be connected to
process controller ramp function generator
(PCTRL1-RFG2)
17 DCTRL1-H/Re 255 Not assigned (FIXED-FREE) Manual/remote changeover
18 PCTRL1-I-OFF 255 Not assigned (FIXED-FREE) Switch off I-component of the process
controller
19 PCTRL1-OFF 255 Not assigned (FIXED-FREE) Process controller switch off
20 Reserved 255 Not assigned (FIXED-FREE) Do not change 255!
21 PCTRL1-STOP 255 Not assigned (FIXED-FREE) Process controller stop (value ”frozen”)
22 DCTRL1-CW/QSP 255 Not assigned (FIXED-FREE)
Failsafe change of the direction of rotation
23 DCTRL1-CCW/QSP 255 Not assigned (FIXED-FREE)
g
24 DFIN1-ON 255 Not assigned (FIXED-FREE) 0 = Frequency input not active
1 = Frequency input active
Frequency input configuration under C0425
and C0426
